The Topology CIF dictionary provides data items for describing crystal structure topology. This is a DRAFT version and data items in this dictionary should not be used until final approval by COMCIFS.

Category tree view of data-item definitions

TOPOL
CIF
The TOPOL category covers data on connectivity
between atoms and structural groups and the
related structural properties as calculated from
the ATOM, CELL and SPACE_GROUP data.
save_TOPOL

    _definition.id                TOPOL
    _definition.scope             Category
    _definition.class             Set
    _definition.update            2021-09-27
    _description.text
;
    The TOPOL category covers data on connectivity
    between atoms and structural groups and the
    related structural properties as calculated from
    the ATOM, CELL and SPACE_GROUP data.
;
    _name.category_id             TOPOLOGY
    _name.object_id               TOPOL

    # Following have been imported above:
#_import.get
#        [{'file':topo_examples.cif  'save':topol_examples}]

save_
_topol.special_details
CIF
A description of topological information not covered by the
existing data items in the topology categories.
save_topol.special_details

    _definition.id                '_topol.special_details'
    _definition.update            2021-09-14
    _description.text
;
    A description of topological information not covered by the
    existing data items in the topology categories.
;
    _name.category_id             topol
    _name.object_id               special_details
    _type.purpose                 Describe
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

save_
TOPOL_ATOM
CIF
The TOPOL_ATOM category provides information on the atoms of the initial
structure that compose links or nodes of a net. The _topol_atom.atom_label
value must match a value for _atom_site.label.
save_TOPOL_ATOM

    _definition.id                TOPOL_ATOM
    _definition.scope             Category
    _definition.class             Loop
    _definition.update            2021-08-29
    _description.text
;
    The TOPOL_ATOM category provides information on the atoms of the initial
    structure that compose links or nodes of a net. The _topol_atom.atom_label
    value must match a value for _atom_site.label.
;
    _name.category_id             TOPOLOGY
    _name.object_id               TOPOL_ATOM
    _category_key.name            '_topol_atom.id'

save_
_topol_atom.atom_label
CIF
A pointer to an atom that is associated with a link or a node
(not including link end-point atoms). It must coincide with a
value given for _atom_site.label.
save_topol_atom.atom_label

    _definition.id                '_topol_atom.atom_label'
    _definition.update            2021-11-16
    _description.text
;
    A pointer to an atom that is associated with a link or a node
    (not including link end-point atoms). It must coincide with a
    value given for _atom_site.label.
;
    _name.category_id             topol_atom
    _name.object_id               atom_label
    _name.linked_item_id          '_atom_site.label'
    _type.purpose                 Link
    _type.source                  Related
    _type.container               Single
    _type.contents                Word

save_
_topol_atom.element_symbol
CIF
The element symbol for this atom, written in accordance with
the IUPAC systematic nomenclature for periodic elements. This should be
a single element symbol found on the official IUPAC Periodic Table.
For example: 'C', 'H', or 'Co', without isotope or charge.
Data items in the ATOM_SITE category that do not correspond to elements
of the Periodic Table should be represented here as '.'.
save_topol_atom.element_symbol

    _definition.id                '_topol_atom.element_symbol'
    _definition.update            2021-09-05
    _description.text
;
    The element symbol for this atom, written in accordance with
    the IUPAC systematic nomenclature for periodic elements. This should be
    a single element symbol found on the official IUPAC Periodic Table.
    For example: 'C', 'H', or 'Co', without isotope or charge.
    Data items in the ATOM_SITE category that do not correspond to elements
    of the Periodic Table should be represented here as '.'.
;
    _name.category_id             topol_atom
    _name.object_id               element_symbol
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

save_
_topol_atom.id
CIF
The unique identifier of a topological "atom" that
is associated with a link or node.
save_topol_atom.id

    _definition.id                '_topol_atom.id'
    _definition.update            2021-10-08
    _description.text
;
    The unique identifier of a topological "atom" that
    is associated with a link or node.
;
    _name.category_id             topol_atom
    _name.object_id               id
    _type.purpose                 Key
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_atom.node_id
CIF
The node associated with this atom, if applicable.
It must match a value provided for _topol_node.id.
save_topol_atom.node_id

    _definition.id                '_topol_atom.node_id'
    _definition.update            2021-10-08
    _description.text
;
    The node associated with this atom, if applicable.
    It must match a value provided for _topol_node.id.
;
    _name.category_id             topol_atom
    _name.object_id               node_id
    _name.linked_item_id          '_topol_node.id'
    _type.purpose                 Link
    _type.source                  Related
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_atom.symop_id
CIF
The identifier of the symmetry operation that is to be
applied to the coordinates of the atom given by
_topol_atom.atom_label before addition of
the translations given by _topol_atom.translation.
The value must match a value of _space_group_symop.id.
If this item is omitted or assigned to '.', the identity
operation is assumed.
save_topol_atom.symop_id

    _definition.id                '_topol_atom.symop_id'
    _definition.update            2021-11-16
    _description.text
;
    The identifier of the symmetry operation that is to be
    applied to the coordinates of the atom given by
    _topol_atom.atom_label before addition of
    the translations given by _topol_atom.translation.
    The value must match a value of _space_group_symop.id.
    If this item is omitted or assigned to '.', the identity
    operation is assumed.
;
    _name.category_id             topol_atom
    _name.object_id               symop_id
    _name.linked_item_id          '_space_group_symop.id'
    _type.purpose                 Link
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:192
    _enumeration.default          1
    _units.code                   none

save_
_topol_atom.translation
CIF
The lattice translation vector that must be added to the
coordinates after application of the symmetry operation specified by
_topol_atom.symop_id to generate the atom belonging to
a link or a node.  For example, if the symmetry operation
referred to by _topol_atom.symop_id is
(x-1/2,y+1/2,z), _topol_atom.translation is [0,-1,0]
and the original position is (0.2,0.7,1.0) in fractional coordinates,
then the resultant position is (-0.3,0.2,1.0). Alternatively,
_topol_atom.translation_x,
_topol_atom.translation_y and
_topol_atom.translation_z data items may be used to
describe separate components of the vector for CIF 1 compatibility.
If this item is omitted or
assigned to '.' it is assumed to be equal to [0,0,0].
save_topol_atom.translation

    _definition.id                '_topol_atom.translation'
    _definition.update            2021-10-21
    _description.text
;
    The lattice translation vector that must be added to the
    coordinates after application of the symmetry operation specified by
    _topol_atom.symop_id to generate the atom belonging to
    a link or a node.  For example, if the symmetry operation
    referred to by _topol_atom.symop_id is
    (x-1/2,y+1/2,z), _topol_atom.translation is [0,-1,0]
    and the original position is (0.2,0.7,1.0) in fractional coordinates,
    then the resultant position is (-0.3,0.2,1.0). Alternatively,
    _topol_atom.translation_x,
    _topol_atom.translation_y and
    _topol_atom.translation_z data items may be used to
    describe separate components of the vector for CIF 1 compatibility.
    If this item is omitted or
    assigned to '.' it is assumed to be equal to [0,0,0].
;
    _name.category_id             topol_atom
    _name.object_id               translation
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Matrix
    _type.dimension               '[3]'
    _type.contents                Integer
    _enumeration.default          [0  0  0]
    _units.code                   none

save_
_topol_atom.translation_x
CIF
The x component of the vector of lattice translations that is added
to the coordinates after application of the symmetry operation given by
_topol_atom.symop_id to generate an atom belonging to a link or a node.
Default value is 0.
save_topol_atom.translation_x

    _definition.id                '_topol_atom.translation_x'
    _definition.update            2021-10-21
    _description.text
;
     The x component of the vector of lattice translations that is added
     to the coordinates after application of the symmetry operation given by
     _topol_atom.symop_id to generate an atom belonging to a link or a node.
     Default value is 0.
;
    _name.category_id             topol_atom
    _name.object_id               translation_x
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.default          0
    _units.code                   none

save_
_topol_atom.translation_y
CIF
The y component of the vector of lattice translations that is added
to the coordinates after application of the symmetry operation given by
_topol_atom.symop_id to generate an atom belonging to a link or a node.
Default value is 0.
save_topol_atom.translation_y

    _definition.id                '_topol_atom.translation_y'
    _definition.update            2021-10-21
    _description.text
;
    The y component of the vector of lattice translations that is added
    to the coordinates after application of the symmetry operation given by
    _topol_atom.symop_id to generate an atom belonging to a link or a node.
    Default value is 0.
;
    _name.category_id             topol_atom
    _name.object_id               translation_y
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.default          0
    _units.code                   none

save_
_topol_atom.translation_z
CIF
The z component of the vector of lattice translations that is added
to the coordinates after application of the symmetry operation given by
_topol_atom.symop_id to generate an atom belonging to a link or a node.
Default value is 0.
save_topol_atom.translation_z

    _definition.id                '_topol_atom.translation_z'
    _definition.update            2021-10-21
    _description.text
;
    The z component of the vector of lattice translations that is added
    to the coordinates after application of the symmetry operation given by
    _topol_atom.symop_id to generate an atom belonging to a link or a node.
    Default value is 0.
;
    _name.category_id             topol_atom
    _name.object_id               translation_z
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.default          0
    _units.code                   none

save_
TOPOL_ENTANGL
CIF
The TOPOL_ENTANGL category describes entanglements in the
underlying net.  This category is a placeholder for future development
of descriptions of entanglement.
save_TOPOL_ENTANGL

    _definition.id                TOPOL_ENTANGL
    _definition.scope             Category
    _definition.class             Set
    _definition.update            2018-01-30
    _description.text
;
    The TOPOL_ENTANGL category describes entanglements in the
    underlying net.  This category is a placeholder for future development
    of descriptions of entanglement.
;
    _name.category_id             TOPOLOGY
    _name.object_id               TOPOL_ENTANGL

save_
TOPOL_NET
CIF
The TOPOL_NET category describes an atomic network or underlying net.
Reference: Delgado-Friedrichs, O., Foster, M. D., O'Keeffe, M.,
Proserpio, D. M., Treacy, M. M. J. & Yaghi, O. M. (2005).
What do we know about three-periodic nets?
J. Solid State Chem. 178, 2533-2554,
DOI:10.1016/j.jssc.2005.06.037.
save_TOPOL_NET

    _definition.id                TOPOL_NET
    _definition.scope             Category
    _definition.class             Loop
    _definition.update            2021-09-15
    _description.text
;
    The TOPOL_NET category describes an atomic network or underlying net.

    Reference: Delgado-Friedrichs, O., Foster, M. D., O'Keeffe, M.,
          Proserpio, D. M., Treacy, M. M. J. & Yaghi, O. M. (2005).
	  What do we know about three-periodic nets?
          J. Solid State Chem. 178, 2533-2554,
          DOI:10.1016/j.jssc.2005.06.037.
;
    _name.category_id             TOPOLOGY
    _name.object_id               TOPOL_NET
    _category_key.name            '_topol_net.id'

save_
_topol_net.genus
CIF
The genus of the underlying net, defined as the cyclomatic number of
its own quotient graph: g = 1 + e - v, where e and v are the number
of edges and vertices in the quotient graph.  The quotient graph is
a finite graph that contains all of the information of the periodic
net: the vertices of the graph are the vertices of a translational
repeat unit and the edges are all the edges of the repeat unit.
Reference: Delgado-Friedrichs, O. & O'Keeffe, M.
(2005). Crystal nets as graphs: Terminology and definitions.
J. Solid State Chem. 178, 2480-2485,
DOI:10.1016/j.jssc.2005.06.011.
save_topol_net.genus

    _definition.id                '_topol_net.genus'
    _definition.update            2021-10-08
    _description.text
;
    The genus of the underlying net, defined as the cyclomatic number of
    its own quotient graph: g = 1 + e - v, where e and v are the number
    of edges and vertices in the quotient graph.  The quotient graph is
    a finite graph that contains all of the information of the periodic
    net: the vertices of the graph are the vertices of a translational
    repeat unit and the edges are all the edges of the repeat unit.

    Reference: Delgado-Friedrichs, O. & O'Keeffe, M.
    (2005). Crystal nets as graphs: Terminology and definitions.
    J. Solid State Chem. 178, 2480-2485,
    DOI:10.1016/j.jssc.2005.06.011.
;
    _name.category_id             topol_net
    _name.object_id               genus
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _units.code                   none

save_
_topol_net.id
CIF
The unique integer identifier for this net, generally
a serial number starting with 1.
save_topol_net.id

    _definition.id                '_topol_net.id'
    _definition.update            2021-10-08
    _description.text
;
    The unique integer identifier for this net, generally
    a serial number starting with 1.
;
    _name.category_id             topol_net
    _name.object_id               id
    _type.purpose                 Key
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_net.label
CIF
An optional not-necessarily unique label for this net.
save_topol_net.label

    _definition.id                '_topol_net.label'
    _definition.update            2021-09-05
    _description.text
;
    An optional not-necessarily unique label for this net.
;
    _name.category_id             topol_net
    _name.object_id               label
    _type.purpose                 Key
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

save_
_topol_net.overall_topology_EPINET
CIF
The identifier for the overall topology as listed
in the EPINET database at http://epinet.anu.edu.au.
Example:
sqc6
save_topol_net.overall_topology_epinet

    _definition.id                '_topol_net.overall_topology_EPINET'
    _definition.update            2018-01-30
    _description.text
;
    The identifier for the overall topology as listed
    in the EPINET database at http://epinet.anu.edu.au.
;
    _name.category_id             topol_net
    _name.object_id               overall_topology_EPINET
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text
    _description_example.case     sqc6

save_
_topol_net.overall_topology_IZA
CIF
The three-letter symbol for a Zeolite Framework Types that has
been approved by the Structure Commission of the International
Zeolite Association (IZA-SC).
Reference: Database for Zeolite Structures
http://www.iza-structure.org/databases/
Example:
FAU
save_topol_net.overall_topology_iza

    _definition.id                '_topol_net.overall_topology_IZA'
    _definition.update            2018-01-30
    _description.text
;
    The three-letter symbol for a Zeolite Framework Types that has
    been approved by the Structure Commission of the International
    Zeolite Association (IZA-SC).

    Reference: Database for Zeolite Structures
    http://www.iza-structure.org/databases/
;
    _name.category_id             topol_net
    _name.object_id               overall_topology_IZA
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text
    _description_example.case     FAU

save_
_topol_net.overall_topology_RCSR
CIF
The overall topology symbol according to the RCSR nomenclature described
by O'Keeffe et al. (2008).
Reference: O'Keeffe, M., Peskov, M. A., Ramsden, S. J. & Yaghi, O. M.
(2008). The Reticular Chemistry Structure Resource (RCSR) Database of,
and Symbols for, Crystal Nets. Acc. Chem. Res. 41, 1782-1789,
DOI:10.1021/ar800124u.
Example:
dia
save_topol_net.overall_topology_rcsr

    _definition.id                '_topol_net.overall_topology_RCSR'
    _definition.update            2021-09-15
    _description.text
;
    The overall topology symbol according to the RCSR nomenclature described
    by O'Keeffe et al. (2008).

    Reference: O'Keeffe, M., Peskov, M. A., Ramsden, S. J. & Yaghi, O. M.
    (2008). The Reticular Chemistry Structure Resource (RCSR) Database of,
    and Symbols for, Crystal Nets. Acc. Chem. Res. 41, 1782-1789,
    DOI:10.1021/ar800124u.
;
    _name.category_id             topol_net
    _name.object_id               overall_topology_RCSR
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text
    _description_example.case     dia

save_
_topol_net.overall_topology_SP
CIF
The overall topology symbol according to the nomenclature of
Fischer for sphere packings described by Koch et al. (2006).
Reference: Koch, E., Fischer, W. & Sowa, H. (2006). Interpenetration
of homogeneous sphere packings and of two-periodic layers of spheres.
Acta Cryst. A62, 152-167, DOI:10.1107/S010876730600362X.
Example:
4/6/c1
save_topol_net.overall_topology_sp

    _definition.id                '_topol_net.overall_topology_SP'
    _definition.update            2021-09-15
    _description.text
;
    The overall topology symbol according to the nomenclature of
    Fischer for sphere packings described by Koch et al. (2006).

    Reference: Koch, E., Fischer, W. & Sowa, H. (2006). Interpenetration
    of homogeneous sphere packings and of two-periodic layers of spheres.
    Acta Cryst. A62, 152-167, DOI:10.1107/S010876730600362X.
;
    _name.category_id             topol_net
    _name.object_id               overall_topology_SP
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text
    _description_example.case     4/6/c1

save_
_topol_net.overall_topology_TOPOS
CIF
The overall topology symbol according to the TOPOS nomenclature. TOPOS
symbols NDn are interpreted as follows: N is a sequence of degrees
(coordination numbers) of all independent nodes; D is one of the letters
C (chain), L (layer) or T (three-periodic) designating the dimensionality
of the net; and n enumerates non-isomorphic nets with a given ND sequence.
For finite (molecular) graphs the symbols NMk-n are used, where k is the
number of vertices (atoms) in the graph.
Reference: Aman, F., Asiri, A. M., Siddiqui, W. A., Arshad, M. N.,
Ashraf, A., Zakharov, N. S. & Blatov, V. A. (2014). Multilevel
topological description of molecular packings in 1,2-benzothiazines.
Cryst. Eng. Comm, 16, 1963-1970, DOI:10.1039/C3CE42218F.
Example:
3,3,4T3
save_topol_net.overall_topology_topos

    _definition.id                '_topol_net.overall_topology_TOPOS'
    _definition.update            2021-09-15
    _description.text
;
    The overall topology symbol according to the TOPOS nomenclature. TOPOS
    symbols NDn are interpreted as follows: N is a sequence of degrees
    (coordination numbers) of all independent nodes; D is one of the letters
    C (chain), L (layer) or T (three-periodic) designating the dimensionality
    of the net; and n enumerates non-isomorphic nets with a given ND sequence.
    For finite (molecular) graphs the symbols NMk-n are used, where k is the
    number of vertices (atoms) in the graph.

    Reference: Aman, F., Asiri, A. M., Siddiqui, W. A., Arshad, M. N.,
    Ashraf, A., Zakharov, N. S. & Blatov, V. A. (2014). Multilevel
    topological description of molecular packings in 1,2-benzothiazines.
    Cryst. Eng. Comm, 16, 1963-1970, DOI:10.1039/C3CE42218F.
;
    _name.category_id             topol_net
    _name.object_id               overall_topology_TOPOS
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text
    _description_example.case     3,3,4T3
    _description_example.detail
;
    The third non-isomorphic three-periodic trinodal net with two 3-coordinated
    and one 4-coordinated independent nodes.
;

save_
_topol_net.period
CIF
The periodicity of the underlying net.
save_topol_net.period

    _definition.id                '_topol_net.period'
    _definition.update            2021-09-17
    _description.text
;
    The periodicity of the underlying net.
;
    _name.category_id             topol_net
    _name.object_id               period
    _type.purpose                 State
    _type.source                  Derived
    _type.container               Single
    _type.contents                Code

    loop_
      _enumeration_set.state
      _enumeration_set.detail
         0                        '0-periodic (finite)'
         1                        '1-periodic (chain)'
         2                        '2-periodic (layer)'
         3                        '3-periodic (framework)'

save_
_topol_net.special_details
CIF
An arbitrary description of the net.
save_topol_net.special_details

    _definition.id                '_topol_net.special_details'
    _definition.update            2021-05-03
    _description.text
;
    An arbitrary description of the net.
;
    _name.category_id             topol_net
    _name.object_id               special_details
    _type.purpose                 Describe
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

save_
_topol_net.td10
CIF
The topological density TD10 of the underlying net. This is the cumulative
sum of the first ten shells of topological neighbours including the central
atom. For structures with more than one kind of vertex in the asymmetric
unit the value given is a weighted average over the vertices.
save_topol_net.td10

    _definition.id                '_topol_net.td10'
    _definition.update            2021-10-08
    _description.text
;
    The topological density TD10 of the underlying net. This is the cumulative
    sum of the first ten shells of topological neighbours including the central
    atom. For structures with more than one kind of vertex in the asymmetric
    unit the value given is a weighted average over the vertices.
;
    _name.category_id             topol_net
    _name.object_id               td10
    _type.purpose                 Number
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _units.code                   none

save_
_topol_net.total_point_symbol
CIF
The total point symbol of the underlying net.  This value summarizes all
the point symbols for the non-equivalent nodes with their stoichiometric
coefficients.
Examples:
{6^6}
{4.6^2}2{4^2.6^10.8^3}
save_topol_net.total_point_symbol

    _definition.id                '_topol_net.total_point_symbol'
    _definition.update            2018-01-30
    _description.text
;
    The total point symbol of the underlying net.  This value summarizes all
    the point symbols for the non-equivalent nodes with their stoichiometric
    coefficients.
;
    _name.category_id             topol_net
    _name.object_id               total_point_symbol
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

    loop_
      _description_example.case
      _description_example.detail
         '{6^6}'                       'Point symbol for diamond'
         '{4.6^2}2{4^2.6^10.8^3}'      '3,6-coordinated underlying net of TiO2'

save_
_topol_net.z_number
CIF
For 3-periodic nets, the number of symmetry-equivalent nets of this kind
in the crystal structure.
save_topol_net.z_number

    _definition.id                '_topol_net.z_number'
    _definition.update            2021-10-08
    _description.text
;
    For 3-periodic nets, the number of symmetry-equivalent nets of this kind
    in the crystal structure.
;
    _name.category_id             topol_net
    _name.object_id               z_number
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
TOPOL_NODE
CIF
The TOPOL_NODE category, along with TOPOL_ATOM, describes the topological
properties, position and chemical composition
of the nodes of the underlying net. Data items
_topol_node.fract_x, _topol_node.fract_y and _topol_node.fract_z must be
present only if the node's position cannot be derived from
other data items in TOPOL_NODE or TOPOL_ATOM.
Fractional coordinates can be given in other
cases, but are to be considered secondary to calculations based on explicit
or default symmetry transformations, present only for convenience.
In the case of multiple nets, _topol_node.net_id is also required.
Reference: Blatov, V. A., O'Keeffe, M. & Proserpio, D. M. (2010).
Vertex-, face-, point-, Schlfli-, and Delaney-symbols in nets,
polyhedra and tilings: recommended terminology.
Cryst. Eng. Comm. 12, 44-48, DOI:10.1039/B910671E.
save_TOPOL_NODE

    _definition.id                TOPOL_NODE
    _definition.scope             Category
    _definition.class             Loop
    _definition.update            2021-09-15
    _description.text
;
    The TOPOL_NODE category, along with TOPOL_ATOM, describes the topological
    properties, position and chemical composition
    of the nodes of the underlying net. Data items
    _topol_node.fract_x, _topol_node.fract_y and _topol_node.fract_z must be
    present only if the node's position cannot be derived from
    other data items in TOPOL_NODE or TOPOL_ATOM.
    Fractional coordinates can be given in other
    cases, but are to be considered secondary to calculations based on explicit
    or default symmetry transformations, present only for convenience.
    In the case of multiple nets, _topol_node.net_id is also required.

    Reference: Blatov, V. A., O'Keeffe, M. & Proserpio, D. M. (2010).
    Vertex-, face-, point-, Schl\"afli-, and Delaney-symbols in nets,
    polyhedra and tilings: recommended terminology.
    Cryst. Eng. Comm. 12, 44-48, DOI:10.1039/B910671E.
;
    _name.category_id             TOPOLOGY
    _name.object_id               TOPOL_NODE
    _category_key.name            '_topol_node.id'

save_
_topol_node.coordination_sequence
CIF
The coordination sequence is a sequence of numbers counting the
atoms in the 1st, 2nd, 3rd etc. coordination shells of any given
node in the net. In other words, the kth entry in the list is the
number of vertices linked to the node by a path of exactly k
steps. It is usually listed up to k=10. Alternatively, the
_topol_node.coordination_sequence_plain data item can be used to
represent the coordination sequence as plain text.
Example:
[4  12  24  42  64  92  124  162  204  252]
save_topol_node.coordination_sequence

    _definition.id                '_topol_node.coordination_sequence'
    _definition.update            2021-10-08
    _description.text
;
    The coordination sequence is a sequence of numbers counting the
    atoms in the 1st, 2nd, 3rd etc. coordination shells of any given
    node in the net. In other words, the kth entry in the list is the
    number of vertices linked to the node by a path of exactly k
    steps. It is usually listed up to k=10. Alternatively, the
    _topol_node.coordination_sequence_plain data item can be used to
    represent the coordination sequence as plain text.
;
    _name.category_id             topol_node
    _name.object_id               coordination_sequence
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               List
    _type.contents                Integer
    _units.code                   none
    _description_example.case     [4  12  24  42  64  92  124  162  204  252]
    _description_example.detail   'The diamond coordination sequence'

save_
_topol_node.coordination_sequence_plain
CIF
A CIF 1 compatible alternative representation of the coordination sequence
as plain text, as a quoted string of white-space-separated numbers.
Example:
4 12 24 42 64 92 124 162 204 252
save_topol_node.coordination_sequence_plain

    _definition.id                '_topol_node.coordination_sequence_plain'
    _definition.update            2021-07-28
    _description.text
;
    A CIF 1 compatible alternative representation of the coordination sequence
    as plain text, as a quoted string of white-space-separated numbers.
;
    _name.category_id             topol_node
    _name.object_id               coordination_sequence_plain
    _type.purpose                 Encode
    _type.source                  Derived
    _type.container               Single
    _type.contents                Text
    _description_example.case     '4 12 24 42 64 92 124 162 204 252'
    _description_example.detail   'The diamond coordination sequence'

save_
_topol_node.extended_point_symbol
CIF
The extended point symbol of an N-coordinated node lists all shortest
circuits for each of the N(N-1)/2 angles (pairs of edges) incident to
the node. It is written as A(a).B(b)... where A, B, ... designate sizes of
circuits, which meet at angles A, B, ..., and a, b, ... designate numbers
of these circuits. It is sorted so shortest circuits come first. For
a 4-coordinated node connected to nodes w,x,y,z, the angles are ordered
in opposite pairs; wx,yz; wy,xz; wz,xy (written in lexicographic order
smallest numbers first).
Examples:
6(2).6(2).6(2).6(2).6(2).6(2)
4.6(2).4.8(3).6(2).6(2)
7(2).9(2).7(3).7(3).7(3).7(3)
4.4.4.4.6(3).6(3).6(5).6(5).6(5).6(5)
save_topol_node.extended_point_symbol

    _definition.id                '_topol_node.extended_point_symbol'
    _definition.update            2021-10-20
    _description.text
;
    The extended point symbol of an N-coordinated node lists all shortest
    circuits for each of the N(N-1)/2 angles (pairs of edges) incident to
    the node. It is written as A(a).B(b)... where A, B, ... designate sizes of
    circuits, which meet at angles A, B, ..., and a, b, ... designate numbers
    of these circuits. It is sorted so shortest circuits come first. For
    a 4-coordinated node connected to nodes w,x,y,z, the angles are ordered
    in opposite pairs; wx,yz; wy,xz; wz,xy (written in lexicographic order
    smallest numbers first).
;
    _name.category_id             topol_node
    _name.object_id               extended_point_symbol
    _type.purpose                 Encode
    _type.source                  Derived
    _type.container               Single
    _type.contents                Text

    loop_
      _description_example.case
      _description_example.detail
         6(2).6(2).6(2).6(2).6(2).6(2)
             'extended symbol for a vertex in the diamond structure'
         4.6(2).4.8(3).6(2).6(2)
             'extended symbol for one vertex of feldspar net'
         7(2).9(2).7(3).7(3).7(3).7(3)
             'extended symbol for the vertex of qzd net'
         4.4.4.4.6(3).6(3).6(5).6(5).6(5).6(5)
             'extended symbol for the vertex of 5-c sqp net'

save_
_topol_node.fract_x
CIF
The fractional x coordinate of this node. If present, this data item
indicates the final, symmetry-transformed x coordinate of the node.
This data item is only necessary if this node is not referenced
by _topol_atom.node_id.
save_topol_node.fract_x

    _definition.id                '_topol_node.fract_x'
    _definition.update            2021-10-11
    _description.text
;
    The fractional x coordinate of this node. If present, this data item
    indicates the final, symmetry-transformed x coordinate of the node.
    This data item is only necessary if this node is not referenced
    by _topol_atom.node_id.
;
    _name.category_id             topol_node
    _name.object_id               fract_x
    _type.purpose                 Measurand
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Real
    _units.code                   none

save_
_topol_node.fract_x_su
CIF
Standard uncertainty of _topol_node.fract_x.
save_topol_node.fract_x_su

    _definition.id                '_topol_node.fract_x_su'
    _definition.update            2021-10-08
    _description.text
;
    Standard uncertainty of _topol_node.fract_x.
;
    _name.category_id             topol_node
    _name.object_id               fract_x_su
    _name.linked_item_id          '_topol_node.fract_x'
    _type.purpose                 SU
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Real
    _units.code                   none

save_
_topol_node.fract_y
CIF
The fractional y coordinate of this node. If present, this data item
indicates the final, symmetry-transformed y coordinate of the node.
This data item is only necessary if this node is not referenced
by _topol_atom.node_id.
save_topol_node.fract_y

    _definition.id                '_topol_node.fract_y'
    _definition.update            2021-10-11
    _description.text
;
    The fractional y coordinate of this node. If present, this data item
    indicates the final, symmetry-transformed y coordinate of the node.
    This data item is only necessary if this node is not referenced
    by _topol_atom.node_id.
;
    _name.category_id             topol_node
    _name.object_id               fract_y
    _type.purpose                 Measurand
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Real
    _units.code                   none

save_
_topol_node.fract_y_su
CIF
Standard uncertainty of _topol_node.fract_y.
save_topol_node.fract_y_su

    _definition.id                '_topol_node.fract_y_su'
    _definition.update            2021-10-08
    _description.text
;
    Standard uncertainty of _topol_node.fract_y.
;
    _name.category_id             topol_node
    _name.object_id               fract_y_su
    _name.linked_item_id          '_topol_node.fract_y'
    _type.purpose                 SU
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Real
    _units.code                   none

save_
_topol_node.fract_z
CIF
The fractional z coordinate of this node. If present, this data item
indicates the final, symmetry-transformed z coordinate of the node.
This data item is only necessary if this node is not referenced
by _topol_atom.node_id.
save_topol_node.fract_z

    _definition.id                '_topol_node.fract_z'
    _definition.update            2021-10-11
    _description.text
;
    The fractional z coordinate of this node. If present, this data item
    indicates the final, symmetry-transformed z coordinate of the node.
    This data item is only necessary if this node is not referenced
    by _topol_atom.node_id.
;
    _name.category_id             topol_node
    _name.object_id               fract_z
    _type.purpose                 Measurand
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Real
    _units.code                   none

save_
_topol_node.fract_z_su
CIF
Standard uncertainty of _topol_node.fract_z.
save_topol_node.fract_z_su

    _definition.id                '_topol_node.fract_z_su'
    _definition.update            2021-10-08
    _description.text
;
    Standard uncertainty of _topol_node.fract_z.
;
    _name.category_id             topol_node
    _name.object_id               fract_z_su
    _name.linked_item_id          '_topol_node.fract_z'
    _type.purpose                 SU
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Real
    _units.code                   none

save_
_topol_node.id
CIF
The identifier of the node.
save_topol_node.id

    _definition.id                '_topol_node.id'
    _definition.update            2021-10-08
    _description.text
;
    The identifier of the node.
;
    _name.category_id             topol_node
    _name.object_id               id
    _type.purpose                 Key
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_node.label
CIF
An optional not-necessarily unique label for this node.
save_topol_node.label

    _definition.id                '_topol_node.label'
    _definition.update            2021-08-29
    _description.text
;
    An optional not-necessarily unique label for this node.
;
    _name.category_id             topol_node
    _name.object_id               label
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

save_
_topol_node.net_id
CIF
The unique identifier of the net to which this node belongs.
save_topol_node.net_id

    _definition.id                '_topol_node.net_id'
    _definition.update            2021-10-08
    _description.text
;
    The unique identifier of the net to which this node belongs.
;
    _name.category_id             topol_node
    _name.object_id               net_id
    _name.linked_item_id          '_topol_net.id'
    _type.purpose                 Link
    _type.source                  Related
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_node.point_symbol
CIF
The (short) point symbol of the node. This lists the number and size of
the shortest closed chains of connected nodes (circuits) starting from
any non-equivalent node in the net. For an N-coordinated node there are
N(N-1)/2 circuits.
Examples:
6^6
4^2.6^3.8
7^5.9
4^4.6^6
save_topol_node.point_symbol

    _definition.id                '_topol_node.point_symbol'
    _definition.update            2018-02-06
    _description.text
;
    The (short) point symbol of the node. This lists the number and size of
    the shortest closed chains of connected nodes (circuits) starting from
    any non-equivalent node in the net. For an N-coordinated node there are
    N(N-1)/2 circuits.
;
    _name.category_id             topol_node
    _name.object_id               point_symbol
    _type.purpose                 Encode
    _type.source                  Derived
    _type.container               Single
    _type.contents                Text

    loop_
      _description_example.case
      _description_example.detail
         6^6                 'Point symbol for a diamond vertex'
         4^2.6^3.8           'Point symbol for a feldspar 4-coordinated vertex'
         7^5.9               'Point symbol for the vertex of 4-c qzd net'
         4^4.6^6             'Point symbol for the vertex of 5-c sqp net'

save_
_topol_node.symmetry_multiplicity
CIF
The number of different sites that are generated by the
application of the space-group symmetry to the coordinates
given for this site. It is equal to the multiplicity given
for this Wyckoff site in International Tables for Crystallography
Vol. A (2002).
save_topol_node.symmetry_multiplicity

    _definition.id                '_topol_node.symmetry_multiplicity'
    _definition.update            2021-10-08
    _description.text
;
    The number of different sites that are generated by the
    application of the space-group symmetry to the coordinates
    given for this site. It is equal to the multiplicity given
    for this Wyckoff site in International Tables for Crystallography
    Vol. A (2002).
;
    _name.category_id             topol_node
    _name.object_id               symmetry_multiplicity
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:192
    _units.code                   none

save_
_topol_node.vertex_symbol
CIF
The vertex symbol of a node provides similar information to the
_topol_node.extended_point_symbol, but only for rings, which are circuits
that contain no shortcuts, that is, are not the sum of  two
smaller circuits. There may be circuits that cannot be rings. If
there are no rings meeting at a particular angle of the node, the
symbol '*' is used instead of the 'A^a' symbol. It is sorted so
shortest rings come first. For 4-coordinated nodes only, the
angles are grouped in opposite pairs; ab,cd and ac,bd and ad,bc
(written in lexicographic order smallest numbers first). In the
ordering the symbol '*' is equivalent to zero.
Examples:
6(2).6(2).6(2).6(2).6(2).6(2)
4.6(2).4.8.6.6(2)
7(2).*.7(3).7(3).7(3).7(3)
4.4.4.4.6.6.6(5).6(5).6(5).6(5)
save_topol_node.vertex_symbol

    _definition.id                '_topol_node.vertex_symbol'
    _definition.update            2018-02-06
    _description.text
;
    The vertex symbol of a node provides similar information to the
    _topol_node.extended_point_symbol, but only for rings, which are circuits
    that contain no shortcuts, that is, are not the sum of  two
    smaller circuits. There may be circuits that cannot be rings. If
    there are no rings meeting at a particular angle of the node, the
    symbol '*' is used instead of the 'A^a' symbol. It is sorted so
    shortest rings come first. For 4-coordinated nodes only, the
    angles are grouped in opposite pairs; ab,cd and ac,bd and ad,bc
    (written in lexicographic order smallest numbers first). In the
    ordering the symbol '*' is equivalent to zero.
;
    _name.category_id             topol_node
    _name.object_id               vertex_symbol
    _type.purpose                 Encode
    _type.source                  Derived
    _type.container               Single
    _type.contents                Text

    loop_
      _description_example.case
      _description_example.detail
         6(2).6(2).6(2).6(2).6(2).6(2)      'vertex symbol for diamond'
         4.6(2).4.8.6.6(2)
             'vertex symbol for one vertex of feldspar net'
         7(2).*.7(3).7(3).7(3).7(3)
             'vertex symbol for the vertex of qzd net'
         4.4.4.4.6.6.6(5).6(5).6(5).6(5)
             'vertex symbol for the vertex of 5-c sqp net'

save_
_topol_node.Wyckoff_symbol
CIF
The Wyckoff symbol (letter) as listed in the space-group section
of International Tables for Crystallography, Vol. A (1987).
save_topol_node.wyckoff_symbol

    _definition.id                '_topol_node.Wyckoff_symbol'
    _definition.update            2021-09-24
    _description.text
;
    The Wyckoff symbol (letter) as listed in the space-group section
    of International Tables for Crystallography, Vol. A (1987).
;
    _name.category_id             topol_node
    _name.object_id               Wyckoff_symbol
    _type.purpose                 State
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text



    loop_
      _enumeration_set.state
         a
         b
         c
         d
         e
         f
         g
         h
         i
         j
         k
         l
         m
         n
         o
         p
         q
         r
         s
         t
         u
         v
         w
         x
         y
         z
         \a


# Following have been imported above:
#_import.get   [{'file':templ_enum.cif 'save':Wyckoff_letter}]

save_
TOPOL_TILING
CIF
The TOPOL_TILING category describes the natural tiling
corresponding to the underlying net.  A tiling is a
partition of crystal space using generalized polyhedra, and a
natural tiling is one for which tiles are the smallest possible
that conserve the full symmetry of the net and for which the
faces are all locally strong rings. This means that there is no
single largest face (face with the largest number of vertices)
as such a face will be the sum of the other smaller faces.
The tile signature contains the sizes of the tile faces and
the number of faces of a given size in the tile.
Reference: Blatov, V. A., Delgado-Friedrichs, O., O'Keeffe M. &
Proserpio D. M. (2007). Three-periodic nets and tilings: natural
tilings for nets. Acta Cryst. A63, 418-425,
DOI:10.1107/S0108767307038287.
save_TOPOL_TILING

    _definition.id                TOPOL_TILING
    _definition.scope             Category
    _definition.class             Loop
    _definition.update            2021-10-13
    _description.text
;
    The TOPOL_TILING category describes the natural tiling
    corresponding to the underlying net.  A tiling is a
    partition of crystal space using generalized polyhedra, and a
    natural tiling is one for which tiles are the smallest possible
    that conserve the full symmetry of the net and for which the
    faces are all locally strong rings. This means that there is no
    single largest face (face with the largest number of vertices)
    as such a face will be the sum of the other smaller faces.

    The tile signature contains the sizes of the tile faces and
    the number of faces of a given size in the tile.

    Reference: Blatov, V. A., Delgado-Friedrichs, O., O'Keeffe M. &
    Proserpio D. M. (2007). Three-periodic nets and tilings: natural
    tilings for nets. Acta Cryst. A63, 418-425,
    DOI:10.1107/S0108767307038287.
;
    _name.category_id             TOPOLOGY
    _name.object_id               TOPOL_TILING
    _category_key.name            '_topol_tiling.id'

save_
_topol_tiling.d_size
CIF
The number of distinct (not symmetry-related) chambers in the
tiling as expressed by the Delaney-Dress symbol or just D-symbol,
as a measure of the complexity of the tiling (D-size).
Reference: Blatov, V. A., O'Keeffe, M. & Proserpio, D. M. (2010).
Vertex-, face-, point-, Schlfli-, and Delaney-symbols in nets,
polyhedra and tilings: recommended terminology.
Cryst. Eng. Comm. 12, 44-48, DOI:10.1039/B910671E.
save_topol_tiling.d_size

    _definition.id                '_topol_tiling.d_size'
    _definition.update            2021-10-08
    _description.text
;
    The number of distinct (not symmetry-related) chambers in the
    tiling as expressed by the Delaney-Dress symbol or just D-symbol,
    as a measure of the complexity of the tiling (D-size).

    Reference: Blatov, V. A., O'Keeffe, M. & Proserpio, D. M. (2010).
    Vertex-, face-, point-, Schl\"afli-, and Delaney-symbols in nets,
    polyhedra and tilings: recommended terminology.
    Cryst. Eng. Comm. 12, 44-48, DOI:10.1039/B910671E.
;
    _name.category_id             topol_tiling
    _name.object_id               d_size
    _type.purpose                 Number
    _type.source                  Derived
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_tiling.dual
CIF
The overall topology symbol of the dual net, which  corresponds
to the net of the dual of the natural tiling.
save_topol_tiling.dual

    _definition.id                '_topol_tiling.dual'
    _definition.update            2018-01-30
    _description.text
;
    The overall topology symbol of the dual net, which  corresponds
    to the net of the dual of the natural tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               dual
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

save_
_topol_tiling.edges
CIF
The number of independent tile edges in the natural tiling.
save_topol_tiling.edges

    _definition.id                '_topol_tiling.edges'
    _definition.update            2021-10-08
    _description.text
;
    The number of independent tile edges in the natural tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               edges
    _type.purpose                 Number
    _type.source                  Recorded
    _type.container               Single
    _type.contents                Integer
    _units.code                   none

save_
_topol_tiling.faces
CIF
The number of independent tile faces in the natural tiling.
save_topol_tiling.faces

    _definition.id                '_topol_tiling.faces'
    _definition.update            2021-10-08
    _description.text
;
    The number of independent tile faces in the natural tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               faces
    _type.purpose                 Number
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _units.code                   none

save_
_topol_tiling.id
CIF
The unique identifier of the tiling.
save_topol_tiling.id

    _definition.id                '_topol_tiling.id'
    _definition.update            2021-10-08
    _description.text
;
    The unique identifier of the tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               id
    _type.purpose                 Key
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_tiling.net_id
CIF
The identifier of the net that carries this tiling.
save_topol_tiling.net_id

    _definition.id                '_topol_tiling.net_id'
    _definition.update            2021-10-08
    _description.text
;
    The identifier of the net that carries this tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               net_id
    _name.linked_item_id          '_topol_net.id'
    _type.purpose                 Link
    _type.source                  Related
    _type.container               Single
    _type.contents                Integer
    _enumeration.range            1:
    _units.code                   none

save_
_topol_tiling.signature
CIF
The tiling signature, written in the form
n[A^a.B^b...]+m[C^c.D^d...]+...,
where square brackets envelop tile symbols, n,m,... are stoichiometric
coefficients, A, B, C, D, ... are sizes of tile faces, and a,b,c,d, ...
are numbers of the faces of a given size in the tile.
Examples:
[6^4]
3[4^6]+[4^6.6^8]+[4^12.6^8.8^6]
save_topol_tiling.signature

    _definition.id                '_topol_tiling.signature'
    _definition.update            2021-10-17
    _description.text
;
    The tiling signature, written in the form
    n[A^a.B^b...]+m[C^c.D^d...]+...,
    where square brackets envelop tile symbols, n,m,... are stoichiometric
    coefficients, A, B, C, D, ... are sizes of tile faces, and a,b,c,d, ...
    are numbers of the faces of a given size in the tile.
;
    _name.category_id             topol_tiling
    _name.object_id               signature
    _type.purpose                 Encode
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Text

    loop_
      _description_example.case
      _description_example.detail
         '[6^4]'                               'Natural tiling for diamond'
         '3[4^6]+[4^6.6^8]+[4^12.6^8.8^6]'     'Natural tiling for zeolite LTA'

save_
_topol_tiling.tiles
CIF
The number of independent tiles in the natural tiling.
save_topol_tiling.tiles

    _definition.id                '_topol_tiling.tiles'
    _definition.update            2021-10-08
    _description.text
;
    The number of independent tiles in the natural tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               tiles
    _type.purpose                 Number
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _units.code                   none

save_
_topol_tiling.vertices
CIF
The number of independent tile vertices in the natural tiling.
save_topol_tiling.vertices

    _definition.id                '_topol_tiling.vertices'
    _definition.update            2021-10-08
    _description.text
;
    The number of independent tile vertices in the natural tiling.
;
    _name.category_id             topol_tiling
    _name.object_id               vertices
    _type.purpose                 Number
    _type.source                  Assigned
    _type.container               Single
    _type.contents                Integer
    _units.code                   none

save_

Revision history

Version 0.3.0 (2018-02-23) Changed topol_bond to topol_link using node labels instead of atom
       labels. Added coordinates, multiplicity and Wyckoff symbol to topol_node.
       Added in type and linking information. (J Hester.)
Version 0.4.0 (2018-02-27) Added long-form examples provided by V Blatov. Version for review.
Version 0.5.0 (2018-04-05) Added InChI, SMILES structural formulas and replaced symops with explicit
       symmetry operator ids and vector translations. Clarified bond types.
Version 0.9.0 (2018-05-28) Version for final approval after review. Removed most tags from
       TOPOL_ENTANGL and subcategories.
Version 0.9.1 (2019-07-17) Fixed a few typos. (B. McMahon)
Version 0.9.2 (2021-05-04) Replaced TOPOL_REPRES category by TOPOL_NET; all TOPOL_REPRES categories
       are moved to TOPOL category; Examples 4 and 5 added
Version 0.9.3 (2021-07-28) Added CIF-1.0 equivalents for _topol_link.site_symmetry_translation_1,
       _topol_link.site_symmetry_translation_2, and
       _topol_node.coordination_sequence (B. Hanson and V. Blatov)
Version 0.9.4 (2021-10-13) Added TOPOL_ATOM subcategory, _topol_link.node_id_1,
       _topol_link.node_id_2, _topol_link.structural_formula_InChI,
       _topol_link.structural_formula_SMILES, and _topol_node.id items
       Removed TOPOL_EDGE subcategory
       Renamed _topol_link.site_symmetry_symop_1(2) to _topol_link.symop_1(2)
       _topol_link.site_symmetry_translation_1(2)
       to _topol_link.translation_1(2)
       _topol_node.site_symmetry_symop_1(2) to _topol_node.symop_1(2)
       _topol_node.site_symmetry_translation_1(2)
       to _topol_node.translation_1(2)
       (V. Blatov)
       editorial adjustments, formatting (B. Hanson)

       Corrected the definitions of the _topol_node.fract_x,
       _topol_node.fract_y and _topol_node.fract_z data items. (A. Vaitkus)

       added _topol_net.label
       changing "dataname" to "tag" as per VOl. G 2.2.3.3.4 and 2.2.2(2)
       changing "field" to "data value" or "value" as per Vol. G 2.2.3.1.5
       and 2.2.3.1.7
       changing various terms to "loop" as per Vol. g 2.2.2(4) and 2.2.3.1.7
       updated Example 5 for net.id being a number
       temporarily replaced examples 1-4 with TODO as a reminder to get these
       updated
       changing ATOM_SITE.label to _atom_site.label
       changed "block" or "section" to "data items" or "category"
       changed elemental_symbol to element_symbol
       added _topol_link.net_id
       updated examples 2-4 for _chemical_formula_sum  and ATOM_TYPE
       (B. Hanson)

       added new tags (V. Blatov)
       _topol_link.label
       _topol_net.overall_topology_IZA
       _topol_tiling.id
       _topol_tiling.net_id
       _topol_tiling_tile.tiling_id
       added Example 5; renamed old Example 5 to Example 6 (V. Blatov)

       switched _topol_*.id to Integer/enum 1: (B. Hanson)

       Renamed data items _topol_atom.symop, _topol_link.symop_1 and
       _topol_link.symop_2 to _topol_atom.symop_id, _topol_link.symop_id_1
       and _topol_link.symop_id_2 respectively. Adjusted multiple examples
       and data item definitions to reflect this change. (A. Vaitkus)

       Added an enumeration range of 0: to the _topol_tiling_tile.count
       and _topol_tiling_faces.count data items. (A. Vaitkus)

       Renamed data item _topol_net.overall_topology_rscr to
       _topol_net.overall_topology_RCSR. (A. Vaitkus)

       Updated several descriptions by replacing the term 'tag' with
       'data item' and correcting data item references. (A. Vaitkus)

       Added _topol_node.symop_id and _topol_node.translation* (B. Hanson)

       issue #37 Removed method for _topol_node.fract_* (B. Hanson)

       Added DOIs to multiple references. (A. Vaitkus)

       Renamed _topol_tiling.Dsize to _topol_tiling.d_size and
       _topol_link.Voronoi_solidangle to _topol_link.Voronoi_solid_angle.
       (A. Vaitkus)

       Added enumeration range of 1: to the _topol_tiling.d_size data item.
       Redefined the _topol_net.period data item as an enumeration set.
       (A. Vaitkus)

       Restricted the _topol_node.Wyckoff_symbol data item values
       to a set of case-sensitive enumeration values. (A. Vaitkus)
       Added the _dictionary.uri attribute. (A. Vaitkus)
       Added the 'none' measurement units to the definitions of multiple
       data items. (A. Vaitkus)

       Added multiple standard uncertainty (SU) data items. (A. Vaitkus)

       Added the _dictionary.namespace attribute and changed the DDL
       conformance version from 3.13.1 to 4.1.0.

       Declared the TOPOL_TILING category as looped. (A. Vaitkus)

       Removed the _topol_link.atom_label_1, _topol_link.atom_label_2,
       _topol_link.chemical_formula_IUPAC, _topol_link.chemical_formula_moiety,
       _topol_link.chemical_formula_sum, _topol_link.structural_formula_InChI,
       _topol_link.structural_formula_SMILES, _topol_node.atom_label,
       _topol_node.chemical_formula_IUPAC, _topol_node.chemical_formula_moiety,
       _topol_node.chemical_formula_sum, _topol_node.structural_formula_InChI,
       _topol_node.structural_formula_SMILES, _topol_node.symop_id,
       _topol_node.translation, _topol_node.translation_x,
       _topol_node.translation_y and _topol_node.translation_z data items.
       Adjusted related definitions accordingly. (A. Vaitkus)

       TODO: adjust _category_key.name to allow for optional id in all
       TOPOL_* categories with _topol_*.id, as in CHEMICAL_CONN_BOND
Version 0.9.5 (2021-10-21) Removed _topol_net.occurrence_total                  (B. Hanson)
       Removed TOPOL_OCCURRENCE                             (B. Hanson)
       Removed TOPOL_TILING_FACES and TOPOL_TILING_TILE     (B. Hanson)
       Added _topol_link.type 'gl' (generic link)           (B. Hanson)

       Added machine-readable default values to the definitions
       of multiple data items. (A. Vaitkus)

       NOTE: _topol_net.total_point_symbol
       should display { } correctly in {4.6^2}2{4^2.6^10.8^3}

       NOTE: all ^ should be that mark in the dictionary examples.
Version 0.9.6 (2021-11-16) Updated the _topol_atom.atom_label, _topol_atom.symop_id,
       _topol_link.symop_id_1 and _topol_link.symop_id_2 data items
       to be compatible with the data items that they are linked to.
       (A. Vaitkus)
